Features:
1. Low chassis design makes this wheel loader suitable for special terrain.
2. Special front and rear axles of heavy-duty casting projects to meet the needs of high-strength and high-load operations.
3. The axle case is made of cast steel, hinged at the center, with small turning radius, more reliable and flexible operation under heavy load.
| Model 1.6T | LZ936D-LK | ||
| Rated contained mass | kg | 1600 | |
| Total Weight | kg | 3700 | |
| Bucket capacity | m³ | 0.55 | |
| Bucket width | mm | 1800 | |
| size(L×W×H) | mm | 6000*1890*2200 | |
| wheelbase | mm | 1470 | |
| Axle spacing | mm | 2250 | |
| Max.unloading height | mm | 2600 | |
| Min.turning radius | mm | 4400 | |
| Mini.ground clearance | mm | 260 | |
| Tires size | 20.5/70-16 | ||
| Boom lift | s | 6.5 | |
| Boom down | s | 4.62 | |
| Trinomial sum | s | 10.89 | |
| Driving speed | LowⅠ(F/R) | km/h | 5 |
| LowⅡ(F/R) | km/h | 8.5 | |
| HighⅠ(F/R) | km/h | 18 | |
| HighⅡ(F/R) | km/h | 27 | |
| Engine | model | 4BZ-52M22 | |
| rated power | KW | 36.8 | |
| Rated speed | r/min | 2400 | |
| Emission Standards | Europe II | ||
| Origin | QUANCHAI | ||
FAQ
1: Can I buy other model bucket which adapt for this model loader from your company at same time?
Answer: We provide a variety of buckets for you to choose from, and you can purchase buckets according to your local needs.
2: What is your loader production capacity?
Answer: We have a semi-automatic tractor production line, we produce 6000 loaders per year.
